Dimensions
8 HP
38 mm deep
Current Draw
5 mA +12V
5 mA -12V
? mA 5V
Price
$80 Price in €

This Module is currently available.

Active Buffered Multiple Module

This is an active multiple using TL074 op amp to copy the signal and repeat the patch. I am using a simple design. What goes in, comes out exactly the same. I am not using resistors to play with the ratio's. I also added a 100k to ground clamp so that you can copy even fast clocks, gates, etc and they will not 'stick' together to make one big pulse. It can be a problem with some multiples.

You can have two long 8 repeated outs and one four repeated out, or patch all five inputs to have five sets of four repeated outs.
